BEAVER VALLEY QUARRY
near Port Ludlow, Jefferson County, Washington, USA

GEOLOGY
Crescent Formation - Late Paleocene to middle Eocene (62-48 Ma). The Crescent Formation is comprised of a large volume of submarine/subaerial basalt. The Crescent basalts are among the oldest basalts in this region and makeup the basement of the Coastal range. Babcock et al. (1992) concluded that the Crescent Formation basalts erupted into a subsiding rift basin along the western coast approximately 60 mya. Exposure of the Crescent Formation can be found as a continuous swath defining the northern, eastern, and southeastern edge of the Olympic Peninsula. Based on gravity studies, the Crescent Formation is thought to extend eastward beneath the Puget Sound to Seattle. Most of the Crescent Formation, especially on its eastern edge, is covered with Quaternary glacial till deposits.

Multiple basalt flows exposed at this dormant quarry contain vesicles that show a complex history of sub-greenschist facies (zeolite) mineralization. Mineralization is most prevalent directly above contacts between individual flows. This locality is listed in a mineral collecting pamphlet issued by the Washington State Mineral Council. Access may be subject to change.

MINERALS (complete list, pers. comm., John Cornish) CLICK for PHOTOGRAPHED
   Analcime- NaAlSi2O6×H2O
   Bornite- Cu5FeS4
*Calcite- CaCO3
*Chabazite (Var: Phacolite)-
   Chalcocite- Cu2S
   Chalcopyrite- CuFeS2
*Chlinochlore- (Fe,Mg)3Fe3(Si,Al)4O10(OH)8
*Copper- Cu
   Gonnardite- Na2Ca(Al2Si3O10)26H2O
*Heulandite- (Ca,Na)2-3Al3(Al,Si)2Si13O36 ×12H2O
*Levyne- (Ca,Na2,K2)Al2Si4O126H2O
   Mesolite- Na2Ca2(Al2Si3O10)3×8H2O
   Mordenite- (Na2,K2,Ca)Al2Si10O24×7H2O
   Natrolite- Na2Al2Si3O10×2H2O
*Quartz- SiO2
*Stilbite- NaCa2Al5Si13O36×14H2O
   Thomsonite- NaCa2Al5Si5O206H2O

* photographed

CALCITE


CALCITE


CALCITE on CLINOCHLORE

CALCITE on CLINOCHLORE


CHABAZITE (Var: Phacolite)

COPPER wire on CLINOCHLORE


COPPER wire on CLINOCHLORE

COPPER wire

HEULANDITE

LEVYNE


Drusy QUARTZ
spheres on ropy

CLINOCHLORE

Drusy QUARTZ,
light green
JASPER

STILBITE,
vesicle filling in basalt



UNIDENTIFIED MINERALS
CONTACT me if you can help me identify these minerals


Unidentified #1


REFERENCES

Babcock R. S., Burmester R. F., Engebretson, D. C., Warnock A., Clark K. P. (1992) A rifted origin for the Crescent basalts and related rocks in the northern Coast Range volcanic province, Washington and British Columbia. Journal of Geophysical Research, B, Solid Earth and Planets 97;5, 6799-6821.
